XCELL XP2.3-12 lead-acid battery with VdS approval – 12 V and 2.3 Ah

The XCELL XP1.2-12 is a compact 12-volt AGM lead-acid battery with a nominal capacity of 1.2 Ah. It reliably supplies energy in safety-related devices and industrial applications, impresses with easy integration and defined charging parameters for standby and cyclic operation.Highlights at a glanceCompact and lightweight: 97 x 43 x 58 mm at approx. 0.54 kgVdS approved: G 114095 for safety applicationsMaintenance-free thanks to AGM technology and valve-regulated constructionClear charging windows: Float 13.60 to 13.80 V, Cycle 14.50 to 14.90 VSolid power reserve: up to 18 A discharge current for 5 secondsUse and PerformanceThe XP1.2-12 is designed for alarm and security technology, emergency lighting, communication and measuring devices as well as small control units. The internal impedance of approx. 90 mΩ supports stable voltage supply, even during short load peaks. The permissible discharge range from −15 °C to +50 °C enables operation in different environments.Efficiency and Service LifeIn float operation, an expected service life of 3 to 5 years at 20 °C is envisaged. The self-discharge is low: at 25 °C approx. 91 percent capacity remains after 3 months, 82 percent after 6 months and 65 percent after 12 months of storage. This means the battery remains reliably available even after idle periods.Installation and Charging RecommendationsThe battery has T1 terminals for quick, secure installation. For standby operation, a charging voltage of 13.60 to 13.80 V at 25 °C with temperature compensation of −18 mV per °C is recommended. In cyclic operation, 14.50 to 14.90 V at 25 °C with −30 mV per °C compensation applies. The maximum charging current is 0.36 A.Features  ModelXCELL XP1.2-12 VdS Battery typeVRLA AGM (safety technology) Nominal voltage (V)12 Capacity (Ah)1.2 (at 20h rate) Maximum discharge current18A (for 5 seconds) Charging voltage (standby charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charge: 0 ~ 40 / Discharge: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 5 years (EUROBAT: Standard Commercial) Dimensions (L/W/H, mm)97 x 43 x 58 Weight (kg)approx. 0.57 ConnectionFaston 187 (4.8 mm) CertificationsVdS, ISO9001, CE, UL  FAQs about the XCELL XP1.2-12What is the expected service life of the XP1.2-12 in standby operation?At 20 °C, 3 to 5 years in float operation is envisaged. Regular functional checks and appropriate charging voltage increase availability.For which applications is the XP1.2-12 battery suitable?Preferred for alarm and signalling systems, emergency lighting, communication and measuring devices as well as compact controllers with 12-volt supply.Which charging voltages should be used?In float charge operation, the voltage should be between 13.60 V and 13.80 V at 25 °C. In cyclic operation, the recommended voltage range is 14.50 V to 14.90 V. Please note the temperature compensation.What is the self-discharge rate?At 25 °C, approx. 91 percent of the capacity remains after 3 months, approx. 82 percent after 6 months, and approx. 65 percent after 12 months storage.Which terminals are present on the battery?T1 flat plug terminals for quick integration into devices and assemblies.Which VdS approval does the battery have and is it system-bound?The battery is VdS-approved under number G114095 and the approval is not system-bound.

The XCELL XP7-12 is a valve-regulated AGM battery with 12 volts and a rated capacity of 7 Ah (C20). It impresses with its compact dimensions, high operational reliability and long service life. Thanks to its robust construction and low self-discharge, it is ideally suited for use in security and emergency power systems, medical technology, measurement and control technology, telecommunications, and in numerous mobile and stationary applications.Highlights at a glanceCompact power: 12 V, 7.0 Ah (20h)VdS approved: G 120023 for safety-related applicationsFlexible usage: Any operating position is possible (except permanently upside down)Long-lasting: Up to 5 years design life at 20 °CHigh reliability: Low self-discharge <3 % per month at 25 °CRobust housing: ABS UL94 HBReliable power supply for a wide range of applicationsXCELL ’s XP7-12 delivers consistent performance even under demanding conditions. AGM technology ensures efficient gas recombination, making the battery virtually maintenance-free. With a maximum discharge current capacity of 105 A (5 seconds), it is also suitable for applications with short-term peak loads.Efficiency meets durabilityIn standby mode, the battery should be charged to a voltage of 2.25–2.30 V/cell. For cyclic operation, a charging voltage of 2.45–2.50 V/cell is recommended. The temperature compensation is –3 mV/cell/°C in standby mode and –4 mV/cell/°C in cyclic operation. The recommended maximum current is 0.3C (approx. 2.1 A). In cyclic use, the battery achieves several hundred charge and discharge cycles, depending on the depth of discharge.Technology for flexible applicationsThe operating temperature range of the cells is between –15 °C and +50 °C during charging. During discharge, it is –20 °C to +60 °C, and during storage –20 °C to +50 °C. T1 or T2 plug-in connectors are available for the electrical connection. The recommended tightening torque for this is between 2 and 3 Newton metres. Each cell is also equipped with a safety valve, which further enhances operational safety.Features  ModelXCELL XP7-12 Battery typeVRLA AGM (Standby / General Purpose) Nominal voltage (V)12 Capacity (Ah)7.0 (at 20-hour rate) Maximum discharge current105A (for 5 seconds) Charging voltage (trickle charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charging: 0 ~ 40 / Discharging: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 5 years (EUROBAT: Standard Commercial) Dimensions (L/W/H, mm)151 x 65 x 100 Weight (kg)approx. 2.1 ConnectionFaston 187 (4.8 mm) CertificationsISO9001, CE, UL  FAQ on the XCELL XP7-12 industrial batteryFor which applications is the XP7-12 ideally suited?The XCELL XP7-12 is ideal for emergency power supply, security and fire alarm systems, medical technology, telecommunications, measurement and control technology, as well as mobile devices with cyclic energy requirements.How cycle-stable is the XP7-12?At a 30% depth of discharge, the battery achieves over 1,000 charge and discharge cycles. At higher depths of discharge, the service life is reduced accordingly, but remains in the range of several hundred cycles.What are the specific safety features?The battery is equipped with pressure relief valves. Like all VRLA batteries, it may release small amounts of hydrogen. It should therefore not be operated in airtight enclosures and adequate ventilation must be ensured.Which chargers are suitable for the XP7-12?Constant-voltage chargers designed for VRLA AGM batteries are recommended. Correct setting of the charging voltage and temperature compensation is crucial for a long service life.How is the battery installed?The battery can be installed in any position except permanently upside down. Connection is via T1 or T2 plug-in terminals with a tightening torque of 2–3 Nm.

The XCELL XP12-12F2 is a reliable, valve-regulated lead-acid battery with 12 volts and a capacity of 12 Ah. With 6.3 mm Faston plug-in terminals, compact dimensions and VdS certification (G120034), it is ideal for safety-critical applications such as fire and burglar alarm systems, UPS systems, and medical and industrial equipment. Its leak-proof AGM technology ensures a maintenance-free and long-lasting power supply.Highlights at a glanceVdS approved: G 120034 for safety-related applicationsCompact design: Measuring just 151 x 98 x 95 mm and weighing approx. 4.1 kgReliable performance: 12 Ah capacity at a 20-hour discharge rateHigh discharge current: Up to 180 A (5 sec.) for peak loadsLong-lasting: Up to 5 years’ service life at 25 °C in standby modePowerful performance for demanding applicationsThanks to its robust construction and consistent current output, the XP12-12F2 is suitable for a wide range of applications: from safety-critical systems and telecommunications to medical equipment. The Faston connectors (6.3 mm) enable seamless integration into existing setups. Even during short-term load peaks, the battery reliably delivers power with a discharge current of up to 180 A for 5 seconds.Efficient energy and reliable service lifeAGM technology ensures maintenance-free operation and high reliability. With a float life of up to 5 years (at 25 °C), the battery is characterised by low self-discharge of less than 3% per month, meaning it is ready for immediate use even after prolonged storage. It also impresses with good performance at extreme temperatures ranging from -15 °C (charging) to +60 °C (discharging).Technology for industrial and safety-critical applicationsThe XP12-12F2 features a flame-retardant ABS housing (in accordance with UL94-HB/UL94-V0) and complies with international standards such as ISO 9001, ISO 14001 and OHSAS 18001. The charging voltage is 2.25 – 2.30 V/cell (equivalent to 13.5 – 13.8 V) in standby mode and 2.45 – 2.50 V/cell (equivalent to 14.7 – 15.0 V) in cycle mode at an ambient temperature of 25 °C. Automatic temperature compensation of –3 to –4 mV/°C/cell is integrated.Features  ModelXCELL XP12-12F2 VdS Battery typeVRLA AGM (security technology) Nominal voltage (V)12 Capacity (Ah)12 (at a 20-hour rate) Maximum discharge current180A (for 5 seconds) Charging voltage (trickle charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charging: 0 ~ 40 / Discharging: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 5 years (EUROBAT: Standard Commercial) Dimensions (L/W/H, mm)151 x 98 x 100 Weight (kg)approx. 3.6 ConnectionFaston 250 (6.35 mm) CertificationsVdS, ISO9001, CE, UL  FAQs on the XCELL XP12-12F2 lead-acid batteryHow long does the XCELL XP12-12F2 last in standby mode?Under ideal conditions (25 °C ambient temperature), the expected service life in standby mode is up to 5 years.Is the battery VdS-certified?Yes, the battery has VdS approval with the number G120034 and is therefore suitable for safety-critical applications.What temperature range is the battery suitable for?The battery is designed for a charging range of –15 °C to +50 °C and a discharging range of –20 °C to +60 °C.What is the self-discharge rate?At 25 °C, the battery’s self-discharge rate is less than 3 % per month. It is recommended that the battery be recharged if it has been stored for longer than six months.What charging parameters must be observed?For standby operation, the charging voltage is 13.5–13.8 V. In cyclic operation, it should be 14.7–15.0 V. The temperature compensation is –3 mV/°C/cell in standby operation and –4 mV/°C/cell in cyclic operation.For which applications is this battery particularly suitable?It is suitable for photovoltaic systems, UPS systems, emergency lighting, telecommunications and security technology, alarm and hazard warning systems, as well as for hobby and camping use. However, it is not suitable for starting or traction applications.

The XCELL XP26-12 is a powerful, maintenance-free 12-volt lead-acid battery with a capacity of 26 Ah (20-hour rate), characterised by its long service life. It has been specially developed for reliable, safety-critical and industrial applications. Thanks to its robust AGM technology and M5 inlay terminals, it delivers a high current output. The battery is also VdS-certified (G115073).Highlights at a glanceVdS approved: G 115073 for safety-related applicationsPowerful performance: 26 Ah capacity at a 20-hour discharge rateHigh current output: Up to 390 A discharge current (5 seconds)Long-lasting: Up to 5 years’ service life in standby mode at 25 °CMaintenance-free: Leak-proof AGM technology (VRLA)Powerful performance for demanding applicationsThe XP26-12 ensures a constant and reliable power supply, even during short-term load peaks, with a discharge current of up to 390 A for 5 seconds. With its compact dimensions (165 × 176 × 127 mm) and low weight of approx. 7.9 kg, it is ideal for mobile devices, emergency power supply systems, telecommunications, safety lighting and other industrial applications.Efficient and long-lasting power supplyAGM technology ensures maintenance-free operation with minimal self-discharge of less than 3% per month at 25 °C. A voltage of 13.60–13.80 V is recommended for continuous operation (float charging), whilst 14.50–14.90 V is ideal for cyclic operation. Integrated temperature compensation ensures the efficiency of the charging power regardless of the ambient temperature. The maximum charging power is 7.8 A.Technology for reliable safetyThe battery is fitted with a flame-retardant casing in accordance with UL94-HB/V0 and complies with international standards such as CE, UL and ISO 9001. The design allows for safe operation over several years in standby mode, provided proper maintenance is carried out and ambient temperature conditions are met. Even under difficult conditions, the battery maintains a stable capacity output, approximately 85% at 0 °C and 65% at –15 °C.Features  ModelXCELL XP26-12 VdS Battery typeVRLA AGM (security technology) Nominal voltage (V)12 Capacity (Ah)26 (at a 20-hour rate) Maximum discharge current390A (for 5 seconds) Charging voltage (float charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charging: 0 ~ 40 / Discharging: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 5 years (EUROBAT: High Performance) Dimensions (L/W/H, mm)166 x 175 x 125 Weight (kg)approx. 8.6 ConnectionM5 screw connection CertificationsVdS, ISO9001, CE, UL  FAQs on the XCELL XP26-12What is the service life of the XCELL XP26-12 battery?Depending on operating conditions, the float service life is 3 to 5 years at an ambient temperature of 25 °C.What is the XCELL XP26-12 suitable for?The battery is suitable for safety-critical systems (e.g. fire and burglar alarm systems), UPS systems, telecommunications equipment, medical technology and other industrial applications.Is the XCELL XP26-12 battery VdS-certified?Yes, the XCELL XP26-12 holds VdS approval with the number G115073.What is the self-discharge rate?Self-discharge is less than 3% per month at 25 °C.What charging parameters should be observed?A voltage of 13.60 to 13.80 V is recommended for standby operation. In cyclic operation, the voltage is 14.50 to 14.90 V. The maximum charging current should not exceed 7.8 A.Is the battery maintenance-free, leak-proof and usable in any position?Yes, the XP 26‑12 VDS is maintenance-free, sealed, leak-proof and can be operated in any position.

The XCELL XP18-12 is a high-performance, maintenance-free lead-acid battery renowned for its reliability and longevity. Based on proven AGM (Absorbent Glass Mat) technology, this battery offers a nominal voltage of 12 V and a capacity of 18 Ah. It has been specially developed for demanding stationary and cyclic applications where a constant and reliable power supply is crucial. Thanks to its sealed VRLA design, it is leak-proof and can be operated in any position.Key features at a glanceReliable performance: 18 Ah capacity at 12 V, which corresponds to a total energy of 216 Wh.VdS-approved: G 115072 for safety-related applicationsDurable: Designed for a service life of up to 5 years in accordance with the Eurobat classification.Maintenance-free: VRLA AGM technology eliminates the need to top up with water.Safe and flexible: Fully sealed, leak-proof and suitable for installation in any orientation.Low self-discharge: Ideal for standby operation and seasonal use.Reliable power for critical applicationsThe XCELL XP18-12 is the ideal power solution for systems where reliability is paramount. With its standard dimensions of 181 x 77 x 167 mm and a weight of approximately 5.4 kg, it can be easily integrated as a replacement for existing batteries in a wide range of devices. Its primary areas of application include uninterruptible power supplies (UPS), security and alarm systems, emergency lighting systems, and applications in medical and rehabilitation technology. The wide operating temperature range ensures stable performance even under demanding environmental conditions.Efficiency and safety thanks to AGM technologyThe AGM technology incorporated in the XCELL XP18-12 retains the electrolyte within a glass-fibre mat. This design not only prevents acid leakage but also delivers high vibration resistance and superior cycle stability compared to conventional lead-acid batteries. As no gassing occurs during normal operation, the battery can be used safely indoors and in enclosures without special ventilation. This maximises user safety and reduces maintenance requirements to a minimum.Tried-and-tested, robust lead-acid AGM technologyUnlike open lead-acid batteries, the XP18-12 is valve-regulated and sealed thanks to its VRLA (Valve Regulated Lead Acid) design. This enables internal gas recombination and ensures consistently high performance throughout the battery’s entire service life. The lead-calcium grid plates used contribute to a very low self-discharge rate, making the battery ideal for standby operation or for applications involving prolonged periods of inactivity.Features  ModelXCELL XP18-12 VdS Battery typeVRLA AGM (Safety Technology) Nominal voltage (V)12 Capacity (Ah)18 (at a 20h rate) Maximum discharge current270A (for 5 seconds) Charging voltage (trickle charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charging: 0 ~ 40 / Discharging: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 10 years (EUROBAT: High Performance) Dimensions (L/W/H, mm)181 x 77 x 167 Weight (kg)approx. 5.6 ConnectionM5 screw terminal CertificationsVdS, ISO 9001, CE, UL  FAQs on the XCELL XP18-12 lead-acid batteryWhat does the term AGM stand for?AGM stands for "Absorbent Glass Mat". With this technology, the battery electrolyte is bound within a glass fibre mat. This makes the battery leak-proof, maintenance-free and highly resistant to vibrations.What applications is the XP18-12 battery suitable for?The battery is ideal for uninterruptible power supplies (UPS), alarm systems, fire alarm control panels, emergency lighting systems, and for medical and rehabilitation equipment such as patient lifts or electric wheelchairs.What is the expected service life of the battery?The XCELL XP18-12 is designed for a service life of up to 5 years in standby mode, in accordance with the Eurobat classification. The actual service life depends heavily on the application, the operating temperature and the depth of discharge.Can several XP18-12 batteries be connected in series?Yes, you can connect several batteries of this type together. For a higher voltage (e.g. 24 V), connect two batteries in series. For a higher capacity, connect the batteries in parallel. Please only use batteries of the same type, age and state of charge for this purpose.Is the battery truly maintenance-free?Yes, thanks to its sealed VRLA AGM design, the battery is completely maintenance-free. There is no need to top up with distilled water throughout its entire service life.How should the battery be stored when not in use?Please store the battery in a cool, dry place and ensure that it is fully charged. Due to the low rate of self-discharge, the charge level should be checked every six months and the battery recharged if necessary to prevent deep discharge.

The XCELL XP45-12 is a robust lead-acid battery with a nominal voltage of 12 volts and a capacity of 45 Ah (20-hour rate). Thanks to maintenance-free AGM technology, M6 inlay terminals and VdS certification (G115059), this battery is ideal for safety-critical and industrial applications. It impresses with its high discharge capacity, long service life and reliable performance even under demanding conditions.Highlights at a glanceVdS approved: G 115059 for safety-related applicationsHigh capacity: 45 Ah at a 20-hour discharge rate, 27.9 Ah at a 1-hour loadHigh discharge currents: Up to 450 A possible for 5 secondsLong-lasting: Up to 12 years of float life at 25 °CMaintenance-free: AGM technology with leak-proof designReliable: Low self-discharge (< 3%/month)Reliable performance for demanding industrial applicationsThe XP45-12 is characterised by its robust construction and high current output, making it the ideal choice for a wide range of demanding applications. These include uninterruptible power supply (UPS) systems, emergency lighting, telecommunications equipment and medical technology, as well as other industrial applications. Thanks to its M6 connectors (T4/T9), a stable and reliable connection is guaranteed. Even during brief peak loads, the battery reliably delivers up to 450 A of current, underlining its high performance and reliability.Energy efficiency and extended lifespanThe batteries offer a float life of up to 12 years at 25 °C, making them ideal for long-term use in stationary systems. The recommended charging voltage is 13.50–13.80 V in standby mode and 14.50–14.90 V in cyclic operation. The maximum charging current is limited to 13.5 A. Thanks to the temperature-compensated charging characteristics, energy efficiency is maintained even under fluctuating environmental conditions.Technology for maximum operational reliabilityThe flame-retardant ABS housing meets UL94-HB/V0 standards and provides reliable cell protection. Certifications to UL, CE, ISO 9001 and VdS confirm the product’s high manufacturing quality and safety. Self-discharge is less than 3% per month, ensuring reliable operational readiness even during prolonged storage periods.Features  ModelXCELL XP45-12 VdS Battery typeVRLA AGM (security technology) Nominal voltage (V)12 Capacity (Ah)45 (at a 20-hour rate) Maximum discharge current450A (for 5 seconds) Charging voltage (trickle charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charging: 0 ~ 40 / Discharging: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 10 years (EUROBAT: High Performance) Dimensions (L/W/H, mm)197 x 165 x 170 Weight (kg)approx. 14.0 ConnectionM6 screw terminal CertificationsVdS, ISO9001, CE, UL  FAQs on the XCELL XP45-12 lead-acid batteryWhat is the battery’s service life?Under optimal environmental conditions (25 °C), the XP45-12 has a service life of up to 12 years in float mode.Is the battery VdS-certified?Yes, the VdS approval with the number G115059 confirms its suitability for safety-critical applications such as fire and burglar alarm systems.What temperature range is the XP45-12 battery designed to withstand?The XP45-12 battery is designed for discharge at –15 °C to +50 °C and charging at –10 °C to +50 °C.What is the self-discharge rate?At 25 °C, self-discharge is less than 3% per month; recharging is recommended after 6 months at the latest.What charging parameters apply?For standby operation: 13.50 – 13.80 V.For cyclic operation: 14.50 – 14.90 V.Temperature compensation: –18 mV/°C (float), –30 mV/°C (cycle).Max. charging current: 13.5 A.What is the cycle life of the XP45-12 battery?The XP45-12 battery can withstand up to 400 charge cycles at a 50% discharge rate.
