Vision Lead-acid battery 6FM75TDX Cyclic with 12V and 75Ah

The Vision 6FM50DX is a robust, cycle-resistant lead-acid battery (VRLA) with 12 volts nominal voltage and a capacity of 50 ampere-hours. It is specially designed for demanding applications with recurring charge and discharge cycles. Thanks to the AGM technology (Absorbent Glass Mat), this battery offers a reliable, leak-proof and durable power supply. It is the ideal solution for systems that require high cycle resistance and deep discharges, and is ideally suited for both cyclic and standby operation.Highlights at a glanceCycle-resistant: Developed for a high number of charge and discharge cycles.High capacity: 50 Ah at 12 V (20-hour rate) for long-lasting energy supply.Maintenance-free: Thanks to the leak-proof AGM technology.Low self-discharge: Only approx. 3 % capacity loss per month at 20 °C.Flexible installation: Operation is possible in various positions, except for permanent upside-down mounting.Durable: A service life of up to 10 years in design life.High performance for cyclic applicationsThe 6FM50DX reliably delivers power in recurring discharge cycles. Its capacity is 50 Ah at a 20-hour discharge. Thanks to the special lead-calcium-tin alloy of the grids, it enables high cycle resistance and excellent recovery after deep discharge.Robust technology for demanding environmentsThanks to the VRLA technology with AGM system, the 6FM50DX is absolutely maintenance-free and leak-proof. The electrolyte is safely bound in a glass-fibre mat, enabling safe handling and operation in any position. The battery is equipped with self-closing low-pressure relief valves to ensure pressure equalisation within the cells. The housing is made of robust ABS plastic, which is impact and break-resistant and is also available in a flame-retardant version (UL94:V0) on request. The low self-discharge of about 3% per month enables long-term storage while maintaining a high level of operational readiness.Features  ModelVision 6FM50DX Battery typeVRLA AGM Nominal voltage (V)12 Capacity (Ah)50 (at 20h rate) Max. Discharge current450 A (for 5s) Charging voltage (trickle charge)13.6 V to 13.8 V Charging voltage (cyclic operation)14.4 V to 14.7 V Operating temperature (°C)Charging: -10 ~ 60 / Discharging: -20 ~ 60 Service lifeup to 10 years (according to design life) Dimensions (L/W/H, mm)197 x 165 x 170 Weight (kg)14.6 ConnectionM6 screw terminal CertificationsISO9001, ISO14001, UL  FAQs about the VISION 6FM50DX lead-acid batteryWhat applications is the 6FM50DX best suited for?This battery has been specially developed for cyclic applications where the battery is regularly discharged and recharged. It is ideal as a main power supply for electric vehicles such as wheelchairs and golf caddies, as well as for use in solar systems, telecommunications systems and mobile measuring devices. The battery also holds VdS approval, making it ideal for safety-critical applications such as fire and intruder alarm systems.What does "cycle-resistant" mean?A cycle-resistant battery is specially designed to withstand a high number of charge and discharge cycles without significant loss of capacity or service life. This sets it apart from conventional lead-acid batteries, which are more suited for standby operation.How do I charge the battery correctly?We recommend using a charger designed for AGM batteries with a capacity of 50 Ah. Observe the charging voltages recommended by the manufacturer: 13.6 V to 13.8 V for float charging (standby mode) and 14.4 V to 14.7 V for cycle charging (boost mode). Excessive charging current can shorten the battery's service life..How long does the 6FM50DX battery last?The battery's life expectancy is up to 10 years at 20 °C in design life. However, the actual service life depends greatly on the individual operating conditions, the depth of discharge and the ambient temperature.

The Vision CP1250HF2 is a high-quality, valve-regulated lead-acid battery (VRLA) with 12 Volt nominal voltage and 5 Ah capacity. This HF Series battery is a high-current type specifically designed for demanding standby operation. Equipped with maintenance-free AGM technology, this battery provides an extremely reliable power supply for critical applications that require high performance in a short time, such as in uninterruptible power supplies (UPS).Highlights at a glanceHigh current capability: Optimised for high discharge currents, ideal for powerful UPS systems and other critical loads.Long service life: Designed for a service life of up to 5 years in standby mode (float) at 20 °C.Reliable capacity: 5 Ah at 12 V for secure power supply with a small footprint.Maintenance-free: Fully sealed AGM technology with efficient gas recombination makes maintenance unnecessary.Flexible mounting: Operation is possible in all positions, except permanent use upside down.Tested quality: Manufactured to the highest quality standards, ideal for use in safety-relevant devices.Powerful performance for safety-critical applicationsThe Vision CP1250HF2 delivers a nominal capacity of 5 Ah in a 20-hour discharge. Its particular strength lies in its ability to deliver very high currents for short periods of time. This makes it destined for use in uninterruptible power supplies (UPS) that have to supply high loads when starting up. Its design for standby parallel operation ensures that it provides full power immediately in the event of a power failure.Robust technology for demanding environmentsThanks to the VRLA technology (Valve Regulated Lead Acid) with an electrolyte bound in glass fibre fleece (AGM system), the CP1250HF2 is completely maintenance-free and leak-proof. The battery features self-regulating safety valves that ensure safe pressure equalisation in the event of overcharging. The low self-discharge of less than 3% per month at 20°C enables long-term storage. The robust housing made of impact-resistant ABS plastic is available on request also in a flame-retardant version according to UL94:V0.Features ModelVision CP1250HF2 Battery typeVRLA AGM (high current) Nominal voltage (V)12 Capacity (Ah)5 (at 20h rate) Maximum discharge current75A (for 5 seconds) Charging voltage (float charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charge: 0 ~ 40 / Discharge: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 5 years (EUROBAT: Standard Commercial) Dimensions (L/W/H, mm)90 x 70 x 107 Weight (kg)approx. 1.75 ConnectionFaston 250 (6.35 mm) CertificationsISO9001, ISO14001, CE, UL  FAQs about the Vision CP1250HF2 lead-acid batteryFor which applications is the CP1250HF2 suitable?The battery is ideal for demanding standby applications with high power requirements:Uninterruptible power supplies (UPS)Data centres and telecommunication systemsSafety lighting and emergency lighting systemsFire alarm systems (FAS) and intruder alarm systems (IAS)Medical and clinical devicesWhat does the designation "HF" and "high current capability" mean?The designation "HF" for Vision batteries stands for "High Rate" or high current. These batteries are constructed with thinner lead plates and a larger active surface, resulting in reduced internal resistance. This allows them to deliver significantly higher currents for short periods than standard batteries of the same capacity, which is crucial for starting motors or operating UPS systems.What is the difference compared to a CP1250A standard battery?Although both have the same capacity and size, the CP1250HF2 is specially optimised for high power delivery. The standard battery CP1250A is an all-purpose type. The HF type is the first choice when maximum power output is required in the first few minutes of a power failure, as is the case in UPS systems.What is the correct charging voltage for this battery?For maximum service life in standby operation, the float charge voltage at 20 °C should be between 13.5 V and 13.8 V (2.25 V to 2.30 V per cell). Temperature compensation is recommended for optimal battery maintenance.Is the battery maintenance-free?Yes, thanks to sealed AGM technology, the battery is completely maintenance-free. There is no need to top up with water, and it can be safely operated in devices and indoors.Can I use this battery for an electric scooter?Although the battery would technically work, it is not ideal for this purpose. It is optimised for standby operation. For electric scooters that require daily charge and discharge cycles, we recommend cycle-resistant batteries (recognisable by "DX" on Vision), as these achieve a significantly longer service life in cyclic operation.

The Vision CP12200X is a highly reliable, valve-regulated lead-acid battery (VRLA) with a nominal voltage of 12 volts and a capacity of 20 Ah, which has been specially developed for long-term standby operation in safety-critical systems. Equipped with maintenance-free AGM technology and a service life of up to 10 years, this battery offers an extremely safe and durable emergency power supply. Whether in UPS systems, medical technology or alarm systems, the CP12200X fulfils the highest standards of quality and operational safety.Highlights at a glanceLong service life: Designed for a service life of up to 10 years in standby mode (float) at 20 °C.High capacity: 20 Ah at 12 V for long-lasting power supply in an emergency.Maintenance-free: Fully sealed AGM technology with efficient gas recombination eliminates the need for maintenance.High operational reliability: Leak-proof design and a robust housing ensure safe operation.Low self-discharge: Enables a long shelf life and ensures high readiness for use.Flexible installation: Operation is possible in all positions, except for permanent overhead use.Reliable performance for safety-critical applicationsThe Vision CP12200X provides a capacity of 20 Ah at a 20 hour discharge. Its design is optimised for standby parallel operation, where it is continuously kept at charging voltage in order to provide full performance immediately in the event of a power failure. With its low internal resistance, the battery is capable of supplying high currents for short periods, making it an ideal choice for demanding UPS systems and other safety-relevant systems.Robust technology for demanding environmentsThanks to VRLA technology (Valve Regulated Lead Acid) with an electrolyte bound in fibreglass fleece (AGM system), the CP12200X is absolutely maintenance-free and leak-proof. The battery features self-regulating safety valves that ensure safe pressure equalisation in case of overcharging. The low self-discharge of less than 3 % per month at 20 °C enables long-term storage. The robust housing made of impact-resistant ABS plastic is also available in a flame-retardant version according to UL94:V0 if required.Features  ModelVision CP12200X Battery typeVRLA AGM (Long Life Standby) Nominal voltage (V)12 Capacity (Ah)20 (at 20h rate) Maximum discharge current300A (for 5 seconds) Charging voltage (float charge)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charge: 0 ~ 40 / Discharge: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeup to 10 years (EUROBAT: High Performance) Dimensions (L/W/H, mm)181 x 77 x 167 Weight (kg)approx. 6.0 ConnectionM5 screw terminal CertificationsISO9001, ISO14001, CE, UL  FAQs about the Vision CP12200X lead-acid batteryFor which applications is the CP12200X suitable?The battery is ideally suited for demanding standby applications and emergency power supply:Uninterruptible power supplies (UPS)Safety lighting and emergency lighting systemsFire alarm systems (FAS) and intruder alarm systems (IAS)Telecommunications systems and IT infrastructureMedical and clinical devicesWhat does the long service life of up to 10 years mean?The indication "10 years" refers to the constructive service life (design life) of the battery in standby parallel operation, also called float operation, at a constant ambient temperature of 20°C. The actual service life achieved depends greatly on operating conditions such as ambient temperature, charging voltage and frequency of discharges.What is the difference compared to a standard 5-year battery?The CP12200X uses higher-quality materials and a more robust grid design than standard batteries. This results in less corrosion and wear during continuous charging, which enables the significantly longer service life in standby operation and increases the operational reliability of your systems.What is the correct charging voltage for this battery?For maximum service life in standby operation, the float charge voltage at 20°C should be between 13.5 V and 13.8 V (2.25 V to 2.30 V per cell). Temperature compensation is strongly recommended for optimum maintenance of the battery.Is the battery maintenance-free?Yes, thanks to the sealed AGM technology, the battery is completely maintenance-free. There is no need to top up with water and it can be operated safely in equipment and indoors.Can the battery be installed flexibly?Yes, the battery can be operated in all orientations, except for a permanently overhead mounted position. This enables flexible installation in a wide variety of equipment and systems.

The Vision CP12180DX is a high-performance, cycle-proof and valve-regulated lead-acid battery (VRLA) with 12 Volt nominal voltage and 18 Ah capacity. This battery has been specially developed for demanding cyclic use, where regular and deep discharge is the norm. Equipped with sturdy, maintenance-free AGM technology, it is the ideal energy source for mobile applications in rehabilitation technology, for electric vehicles or for leisure use.Highlights at a GlanceHigh cycle stability: Designed for a long service life during repeated, deep discharge and recharging.Strong capacity: 18 Ah at 12 V for enduring and reliable energy supply for mobile consumers.Maintenance-free AGM technology: The advanced AGM (Absorbent Glass Mat) technology ensures a leak-proof and maintenance-free operation.High power density: Offers a lot of energy in a compact and widely used housing format.Flexible mounting: Operation possible in all positions, except for permanent upside-down use.Low self-discharge: Enables longer shelf life with no significant capacity loss. Strong Performance for Cyclical ApplicationsThe Vision CP12180DX reliably delivers a capacity of 18 Ah with a 20-hour discharge. Its construction is specifically designed for cyclic operation, which gives it high resistance to the stresses of constant charging and discharging. This makes it the perfect choice for electric wheelchairs, golf caddies, e-scooters and other electric vehicles where maximum cycle life and reliability are important.Robust Technology for Demanding EnvironmentsThanks to the VRLA technology (Valve Regulated Lead Acid) in conjunction with the AGM system, where the electrolyte is safely held in a glass fibre mat, the CP12180DX is fully sealed, leak-proof and vibration-resistant. The low internal resistance allows efficient energy delivery even at higher currents. The housing made from robust ABS plastic reliably protects the internal components from mechanical loads in daily mobile use and ensures a long, safe service life.Properties  ModelVision CP12180DX Cyclic Battery typeVRLA AGM (cycle-proof) Nominal voltage (V)12 Capacity (Ah)18 (at 20h rate) Maximum discharge current270A (for 5 seconds) Charging voltage (float charging)13.5V - 13.8V Charging voltage (cyclic operation)14.4V - 15.0V Operating temperature (°C)Charge: 0 ~ 40 / Discharge: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeapprox. 1800 cycles at 30% depth of discharge Dimensions (L/W/H, mm)181 x 77 x 167 Weight (kg)approx. 5.5 ConnectionM5 screw terminal CertificationsISO9001, ISO14001, CE, UL  FAQs about the Vision CP12180DX Lead-Acid BatteryFor which applications is the CP12180DX suitable?The battery is ideally suited for a wide variety of demanding cyclic applications:Electric wheelchairs, mobility scooters and scootersGolf caddies and other lightweight electric vehiclesMedical devices such as patient liftsMobile cleaning machinesApplications in marine and camping areasIs the battery maintenance-free?Yes, thanks to the sealed AGM technology, the battery is completely maintenance-free. No topping up with distilled water is required and it is protected against leakage.What is the difference to a standard AGM battery?The CP12180DX is designed as a cycle-proof battery. It uses reinforced lead plates and special additives, which make it more resistant to the stresses of deep discharges. A standard AGM battery is usually optimised for standby use (e.g. in UPS systems) and would lose capacity more quickly with cyclic use.Can the battery be installed flexibly?Yes, the battery can be operated in all positions, except for permanent upside-down mounting. This enables flexible installation in a wide variety of devices and vehicles.What charging parameters apply to this battery?Cyclic charging voltage (20 °C): approx. 14.4 V to 15.0 V.Float charge voltage (20 °C): approx. 13.5 V to 13.8 V.Maximum charging current: The recommended maximum charging current is 5.4 A. Using a suitable charger is crucial for a long service life.Can two of these batteries be connected to form a 24V system?Yes, you can easily connect two CP12180DX batteries in series to create a 24V system. This is a very common configuration in electric wheelchairs and mobility scooters. Please always use two new, identical batteries for this purpose.

The Vision CP12120D is a high-quality, cycle-resistant and valve-regulated lead-acid battery (VRLA) with a nominal voltage of 12 volts and a capacity of 12 Ah. This battery has been specially developed for demanding cyclic applications and combines a robust design with reliable and maintenance-free AGM technology. It is the ideal energy source for applications that require regular and deep discharge, such as in rehabilitation technology, e-scooters or mobile leisure activities.Highlights at a glanceHigh cycle stability: Designed for a long service life with up to 1600 cycles at 30% depth of discharge.Compact energy: Provides 12 Ah capacity at 12 V in a handy and widely used case format.Maintenance-free AGM technology: The advanced AGM (Absorbent Glass Mat) technology ensures leak-proof and maintenance-free operation.High current carrying capacity: Suitable for consumers with short-term high starting current.Flexible mounting: Operation is possible in all positions, with the exception of permanent overhead use.Low self-discharge: With only about 3% self-discharge per month, the battery is ready for use even after extended periods of non-use.High performance for cyclic applicationsThe CP12120D reliably delivers 12 Ah with a 20-hour discharge (C20). Its strength lies in its high cycle resistance, making it suitable for repeated use. It was designed to ensure stable performance and fast rechargeability even after deep discharges. This makes it the perfect choice for electric vehicles, medical equipment and other mobile applications where reliability is paramount.Robust technology for demanding environmentsThanks to VRLA technology (Valve Regulated Lead Acid) combined with the AGM system, where the electrolyte is safely held in a glass fibre mat, the CP12120D is fully sealed and maintenance-free. This not only prevents acid from leaking, but also ensures high vibration resistance. The low internal resistance of about 18 mΩ enables efficient energy discharge. The case made of robust ABS plastic reliably protects the internal components from mechanical stresses during daily use.Features  ModelVision CP12120D Cyclic Battery typeVRLA AGM (Cycle-resistant) Nominal voltage (V)12 Capacity (Ah)12 (at 20h rate) Maximum discharge current180A (for 5 seconds) Charging voltage (float charge)13.6V - 13.8V Charging voltage (cyclic operation)14.5V - 14.9V Operating temperature (°C)Charge: 0 ~ 40 / Discharge: -20 ~ 50 Storage temperature (°C)-20 ~ 40 Service lifeapprox. 1600 cycles at 30% depth of discharge Dimensions (L/W/H, mm)151 x 98 x 98 Weight (kg)approx. 3.6 ConnectionFaston 6.3 mm CertificationsISO9001, ISO14001, CE, UL  FAQs about the Vision CP12120D lead-acid batteryFor which applications is the CP12120D suitable?The battery is ideal for a variety of cyclic applications:Electric wheelchairs, scooters and other rehab technologyToys and children's electric vehiclesMobile lighting and sound systemsEcho sounders and power supply for fishing boatsCamping and leisure activities Is the battery maintenance-free?Yes, thanks to the sealed AGM technology, the battery is completely maintenance-free. No topping up with distilled water is required and it is protected against leaks in any position.What is the service life of the CP12120D?Service life in cyclic operation is very high and depends on the depth of discharge. With regular discharging to 30%, for example, the battery can achieve up to 1600 cycles.Can the battery be flexibly installed?Yes, the battery can be operated in all positions, with the exception of permanent overhead installation. This enables flexible installation in various devices.What are the charging parameters for this battery?Cyclic charging voltage (20°C): about 14.5 V to 14.9 V.Float charge voltage (20°C): about 13.6 V to 13.8 V.Maximum charging current: The recommended maximum charging current is 3.6 A. Exceeding this may reduce the service life.Can I use this battery as a replacement for a standard lead-acid battery?Yes, in many cases this AGM battery can replace a conventional lead-acid or gel battery with the same specifications (voltage, capacity and dimensions) and often offers advantages such as higher cycle stability and absolute maintenance freedom.

The Yuasa REC22-12I is a cycle-resistant VRLA industrial battery. It supplies 12 volts and 22 Ah (at 20 hours) and features a high cycle life, low impedance and stable power output in a compact design. It is ideally suited for a wide range of applications, including mobile devices, cleaning machines, rehabilitation and medical technology, photovoltaic buffering, measurement and control technology, as well as UPS systems in cyclic operation.Highlights at a glanceCycle-resistant: Up to 1400 cycles at 25 percent DODReliable capacity: 22 Ah at 20-hour discharge to 10.5 V, 19.7 Ah at 10-hour discharge to 10.8 V.Flexible installation: Operation possible in any position, except permanently upside down.Low self-discharge: About 3 percent per month at 20 °C.Case material: ABS to UL94 HB.Maximum performance for demanding cycle applicationsThe REC22-12I is designed for repeated charging and discharging operations. AGM technology and valve-regulated oxygen recombination ensure efficient gas retention and low maintenance requirements. Low impedance supports high peak currents, so sensitive loads are reliably supplied even with dynamic load profiles.Efficiency meets long service lifeIn standby operation, a float charge voltage of 13.65 V ±1 percent per block is applied, which is adjusted by a temperature compensation of minus 3 mV per cell and degree Celsius. For cyclic or boost charging, 14.52 V ±3 percent per block is provided, with compensation of minus 4 mV per cell and degree Celsius. The recommended current limit is 5.5 A in both float and cyclic operation. The service life in use is confirmed by the EUROBAT classification General Purpose 6 to 9 years and a Yuasa Design Life specification of 7 years at 20 °C.Technology for flexible applicationsThe operating temperature range includes discharge from -15 °C to +40 °C, charging from 0 °C to +40 °C and storage from -15 °C to +50 °C. Each cell is equipped with a low pressure relief valve. As VRLA batteries release hydrogen, it is important not to operate them in gas-tight enclosures and to ensure adequate ventilation.Features  ModelYuasa REC22-12I Battery typeVRLA AGM (cycle-resistant, maintenance-free) Nominal voltage (V)12 Capacity (Ah)22 (at 20h rate) Maximum discharge current220A (for 5 seconds) Charging voltage (float charge)13.5V to 13.8V Charging voltage (cyclic operation)14.4V to 15.0V Operating temperature (°C)-15 ~ 50 Storage temperature (°C)-20 ~ 50 Service lifeHigh cycle life Dimensions (L/W/H, mm)175 x 166 x 125 Weight (kg)8.6 ConnectionM5 thread CertificationsIEC 60896-21+22, UL  FAQ about the Yuasa REC22-12IFor which applications is the REC22-12I typical?The REC22-12I is ideally suited for cyclic operations in the areas of mobility, leisure and industry, as it is designed for high cycle resistance and rapid recovery after deep discharge. How cycle-resistant is the REC22-12I?The REC22-12I typically exhibits the following cycle resistance up to a remaining capacity of 80%: 300 cycles are possible at 100% depth of discharge (DoD), 500 cycles at 75% DoD, 600 cycles at 50% DoD and 1400 cycles at 25% DoD.Are there any special safety features?VRLA batteries can release hydrogen gas. Ensure sufficient ventilation and avoid operation in hermetically sealed enclosures. Each cell is equipped with a low pressure relief valve.Which chargers or solar charge controllers are suitable?Use constant voltage devices suitable for VRLA-AGM batteries. Observe the voltages specified in the data sheet and take temperature compensation into account.How is the battery installed?The battery can be installed in any position, but not permanently upside down. The electrical connection is made via M5 thread connections. Ensure a tightening torque of 2 to 3 Nm, correct polarity and adequate ventilation.
